Frame Introduction
Built from premium T1000 carbon fiber, this all-mountain frame combines lightweight construction with robust trail performance. The 110-120mm travel suspension absorbs impacts on technical terrain while maintaining pedaling efficiency on climbs. BB92 bottom bracket integration optimizes frame stiffness and drivetrain compatibility. Boost 148x12mm rear spacing supports modern wheel standards and wider tire clearance for improved grip and control. Disc brake mounts deliver consistent stopping power across extended descents. Engineered for 29er wheels, this frame handles demanding trail conditions with precision and responsiveness.
About Carbon Suspension Frame
Type:Carbon All Mountain Suspension Frame
Model:MEINIER-M10
Material:T1000 Carbon Fiber
Frame Travel:135mm or 150mm
MAX Tire size:27.5erX2.8 ,29erX2.35
Rear Shock:185x50/185x55/190x50/200x57
Rear Hub: 148x12mm boost
Bottom Bracket:BB92
Headset Size:Top 1-1/8", Down 1-1/2"
Seatpost Size:31.6mm
Seatpost clamp Size:34.9mm
Disc brake:160mm
Frame Spencifications
| Type | Carbon All Mountain Suspension Frame |
| Model | MEINIER-M10 |
| Material | T1000 Carbon Fiber |
| Frame Travel | 135mm or 150mm |
| MAX Tire size | 27.5erX2.8 ,29erX2.35 |
| Rear Shock | 185x50/185x55/190x50/200x57 |
| Rear Hub | 148x12mm boost |
| Bottom Bracket | BB92 |
| Headset Size | Top 1-1/8", Down 1-1/2" |
| Seatpost Size | 31.6mm |
| Seatpost clamp Size | 34.9mm |
| Disc brake | 160mm |
| Cable | Internal cable routing |
| Color | Can cutomized colors |
| Product Includes | Frame+Thru axle |
Gravel Frame GR056 Geometry
This gravel frame's geometry is strategically tuned for off-road mastery, combining a forgiving riding position with exceptional terrain feedback. The frame design distributes your weight for optimal stability across loose and broken surfaces, while maintaining the agility needed for technical sections. The result is a platform that rewards both endurance and precision on demanding gravel routes.
Custom Painting Services:
We are carbon fiber factory in China.we have a professional design and painting team to provide you with professional customized painting services. Our service allows you to create a personalized paint job that truly makes your bike stand out.
You can contact us and we can customize the color and logo for you.
Experience versatile trail performance with this full suspension mountain bike frame engineered for modern riding demands. Carbon fiber construction delivers a responsive platform that handles technical descents and climbing challenges with equal competence. The 29er wheel compatibility provides momentum and rollover capability across varied terrain. Boost spacing and disc brake integration align with current industry standards, ensuring seamless component compatibility. Designed for riders who demand a capable, lightweight frame that excels across diverse trail conditions without compromise.
